CAT D6 LGP

MACHINE KEY DETAILS

Make:

Caterpillar

Model:

D6 LGP

Stock No:

70949

Year:

2019

Hours:

6845

Location:

Southampton

Weight:

23,012 KGS

HP:

215 HP

Enquire Online

Download inspection Report Download Images Download Brochure Get a shipping quote Compare Machine

Rippers available at an additional cost.

View Full Inspection Report

ENGINE

Engine model

C9.3B

Blow by

None

Knocking

None

Air filters

Okay

Any smoke

none

Oil or fuel leaks

None

General running condition

Good

TRANSMISSION

Gear change

Smooth

Steering

Good

Oil leaks

None

Is the transmission noisy?

No

Torque converter

Okay

Controls

Good

General running condition

Good

UNDERCARRIAGE

Shoe width

900mm

Shoe height

60mm

Shoes - any wear in trailing edge

Minimal

Rail height

130mm

Any signs of link failure

No

Average diameter of pins and bushings

70mm

Have pins been turned on chains

No

Sprockets

fair

IDLERS - UNDERCARRIAGE

Left side front idler

535mm, 60%

Left side rear idler

540mm, 60%

Right side rear idler

540mm, 60%

Right side front idler

535mm, 60%

TOP ROLLERS - UNDERCARRIAGE

Left side

195mm, 65%

Right side

193mm, 65%

BOTTOM ROLLERS - UNDERCARRIAGE

Left side roller

200mm approx, 60%

Right side roller

200mm approx, 60%

CAB

Cab mounts - any wear?

None

Any wiring for laser system?

Yes

Back up alarm

Good

Battery isolator switch

Yes

Lights

Working

Wipers

Good

Heater

Good

A/C

Good

Seat condition

Good

Cladding condition

Good

Floor mat condition

Good

Seat belt

Yes

Fire extinguisher

Yes

Horn

Working

Cab glass condition

Good

Cab glass have any cracks

No

Any perspex fitted

No

Steps and grab handles secure?

Yes

BLADE

Main lift rams, wear in pins

Very slight to none

Swivel rams, wear in pins

Very slight to none

Tilt ram, wear?

Slight wear

Ball joint wear

No visible signs of wear

Trunnions wear & shims

No visible signs of wear

Tilt ram

Okay

C Frame

Good

Centre pin

No visible signs of wear

Cutting edge condition

130mm

Have cutting edges been turned?

Yes

General blade condition

Okay

PAINT & DECALS

Any damage to panels

No

Paint condition

Good

Any areas repainted

No

Any rust patches

Some

Condition of decals

To be replaced

DIMENSIONS

Length

Width

Height

Measurements with blade straight

5200mm

4300mm

3250mm

Measurements with blade turned

6770mm

3900mm

3250mm

Measurement from outside to outside of tracks

3300mm

Measurements with blade straight

Length: 5200mm

Width: 4300mm

Height: 3250mm

Measurements with blade turned

Length: 6770mm

Width: 3900mm

Height: 3250mm

Measurement from outside to outside of tracks

Length:

Width: 3300mm

Height:
