CAT D6N LGP

MACHINE KEY DETAILS

Make:

Caterpillar

Model:

D6N LGP

Stock No:

70942

Year:

2019

Hours:

5560

Location:

Southampton

Weight:

17,380 KGS

HP:

170 HP

Enquire Online

Download inspection Report Download Images Download Brochure Get a shipping quote Compare Machine

View Full Inspection Report

ENGINE

Blow by

Minimal

Knocking

No knocking

Air cleaners

Good

Any smoke

Minimal to none

Oil or fuel leaks

None

General running condition

Runs well

TRANSMISSION

Gear change

Good gear change

Steering

Responsive steering

Oil leaks

No

Torque

Good, no juddering / knocks

Controls

Good controls

General running condition

Machine moves well

UNDERCARRIAGE

Shoe width

835mm

Shoe height

50mm, 85%

Shoes - any wear in the trailing edge

Some but nothing serious

Rail height

111mm, 90%

Any signs of link failure

No

Average diameter of pins and bushings

62mm, 95%

Have pins been turned on chains

No

Sprockets

25mm tips, 70mm gape. 90%

IDLERS - UNDERCARRIAGE

Left side front idler

55mm x 20mm, 75%

Left side rear idler

55mm x 20mm, 80%

Right side rear idler

55mm x 20mm, 80%

Right side front

55mm x 20mm, 75%

TOP ROLLERS - UNDERCARRIAGE

Left side roller

174mm x 176mm, 80%

Right side roller

174mm x 176mm, 80%

BOTTOM ROLLERS - UNDERCARRIAGE

Roller 1

180mm x 179mm, 60%

Roller 2

185mm x 183mm, 60%

Roller 3

183mm x 180mm, 60%

Roller 4

183mm x 181mm, 60%

Roller 5

Visual only, 60%

Roller 6

183mm x 182mm, 60%

Roller 7

184mm x 182mm, 60%

Roller 8

179mm x 180mm, 60%

CAB

Cab mounts - any wear

No

Any wiring for laser system

Yes

Back up alarm

Loud and clear

Battery isolator switch

Manual fitted

Lights

All working

Wipers

Good

Heater

Good heat

A/C

Nice & cold

Cladding condition

Good

Floor mat condition

Worn edges

Mirrors

Rear view only

Horn

Loud and clear

Cab mounts

Good mounts

Cab glass condition

Good

Any perspex fitted

None

Steps and grab handles secure?

All fitted and undamaged

BLADE

Blade type

PAT

Blade width

4080mm

Blade height

4080mm

Main lift rams, wear

L/H: 1mm x 1mm, R/H: 1mm x 1mm

Pitch ram, wear

L/H: 1mm x 1mm, R/H: 1mm x 1mm

Tilt ram, wear

3mm x 3mm

Link bar, wear

2mm x 2mm

Ball joint wear

5-7mm

C frame, wear

5-7mm x 5-7mm

Equaliser bar, wear

2mm x 2mm

Face / moldboard

Good condition

Spill rack condition

Undamaged

Cutting edge condition

New

Have the cutting edges been turned

No

General blade condition

Good condition

PAINT & DECALS

Any damage to panels

No

Paint condition

Fair

Any areas repainted

No

Any rust patches

In areas, usual spots

Condition of decals

To be replaced

DIMENSIONS

Length

Width

Height

Measurements with blade straight

5400mm

4080mm

3240mm

Measurements with blade turned

6250mm

3650mm

3240mm

Measurement from outside to outside of tracks

3015mm

Measurements with blade straight

Length: 5400mm

Width: 4080mm

Height: 3240mm

Measurements with blade turned

Length: 6250mm

Width: 3650mm

Height: 3240mm

Measurement from outside to outside of tracks

Length:

Width: 3015mm

Height:
