Komatsu D37PX-23 70507

SOLD
"

MACHINE KEY DETAILS

Make:
Komatsu
Model:
D37PX-23
Stock No:
70507
Year:
2013
Hours:
4540
Location:
Southampton
Weight:
7,660 KG
HP:
91 HP
Back to Current Stock
Download inspection Report Download Images Download Brochure Compare Machine

View Full Inspection Report

ENGINE
Blow By
Minimal
Knocking
No knocking
Any Smoke
On rev up - none when warm
Oil Or Fuel Leaks
None visible
General Running Condition
Runs well
TRANSMISSION
Gear Change
HST is good
Steering
Responsive
Oil leaks
None visible
Is The Transmission Noisy?
No
Controls
Good
General Running Condition
Runs well
U/C
Shoe Width (mm)
600mm
Shoe Height (mm)
27mm, 40 - 50%
Shoes Any Wear In Trailing Edge?
Yes
Rail Height
85mm, 80%
Any Signs Of Link Failure
No
Average Diameter Of Pins And Bushings
40mm, 35 - 40%
Have Pins Been Turned On Chains?
No
Sprockets
6mm tips, Gap is 78mm. 40%
IDLERS
Left Side Front Idler
15mm Thickness, 60%
Right Side Front Idler
15mm Thickness, 60%
TOP ROLLER
Left Side Top Roller
139 & 138mm, 70%
Right Side Top Roller
139 & 137mm, 70%
BOTTOM ROLLERS
Bottom Roller 1
Visual Only, 60%
Bottom Roller 2
L/H: 166mm, 60%. R/H: 165mm, 60%
Bottom Roller 3
L/H: 166mm, 60%. R/H: 166mm, 60%
Bottom Roller 4
L/H: 165mm, 60%. R/H: 166mm, 60%
Bottom Roller 5
L/H: 166mm, 60%. R/H: 166mm, 60%
Bottom Roller 6
Visual Only, 60%
CAB
Cab Mounts - Any Wear?
Yes, O/S Back
Back Up Alarm
Loud and clear
Battery Isolator Switch
Manual and electric
Lights
All lights work
Wipers
All work no washers
A/C
Nice and cold
Cladding Condition
Roof lining torn. rest ok
Floor Mat Condition
Dirty but no damage
Seat Belt
Working as should
Mirrors
Rear view only
Horn
Loud and clear
Cab Glass Condition
Ok apart from perspex
Cab Glass Any Cracks
No cracks
Any Perspex Fitted
Yes, both side windows
Steps And Grab Handles Secure?
All ok, no damage
BLADE
Blade Type
6 Way
Blade Width
3200mm
Blade Height
1100mm
Main Lift Rams, Wear In Pins?
L/H: Top: 3mm, Bottom: 5mm. R/H: Top: 3mm, Bottom: 5mm
Swivel Rams, Wear In Pins?
L/H: Top: 3mm, Bottom: 2mm. R/H: Top: 3mm, Bottom: 4mm
Tilt Ram, Wear?
L/H: 2mm, R/H: 2mm
Ball Joint Wear?
10 - 12mm
Link Ram Wear?
Top: 2mm, Bottom: 2mm
C Frame Wear?
L/H: 4mm, R/H: 10mm
Face / Moldboard
Good, no damage
Spill Rack Codition
Bent
Cutting Edges Condition
50mm Left
Have Cutting Edges Been Turned?
No
General blade Condition
Average to good
PANELS & PAINT / DECALS
Any damege To Panels
Yes
Paint Condition
Average, faded
Any Areas Repainted
Yes, C frame Area
Any Rust Patches
Usual Areas
Condition Of Decals
To Be Replaced
DIMENSIONS
Length
Width
Height
Measurements With Blade Straight (mm)
4250mm
3200mm
2760mm
Measurement With Blade Turned (mm)
4850mm
3000mm
2700mm
Measurement From Outside To Outside Of Tracks
2225mm
Measurements With Blade Straight (mm)
Length: 4250mm
Width: 3200mm
Height: 2760mm
Measurement With Blade Turned (mm)
Length: 4850mm
Width: 3000mm
Height: 2700mm
Measurement From Outside To Outside Of Tracks
Length:
Width: 2225mm
Height:
